Double Cone Blender R&D Model
ABSTER Machines is a leading Double Cone Blender R&D Model manufacturer and exporter,specializing in high-quality blending equipment for laboratory use. The double cone blender R&D lab model features a unique design with two conical parts and a cylindrical shell in the middle. This revolving vessel spins on a horizontal axis, allowing the batch materials to cascade down and scatter particles across the newly exposed surface. This process, known as diffusion, is ideal for blending substances with varying densities and sizes. The Double Cone Blender R&D Model is perfect for handling fragile components and abrasive solids, providing a low-impact and safe blending method.
The Double Cone Blender R&D Model manufacturer offers a reliable solution for laboratories needing precise and efficient mixing. The double cone shape of the vessel that the combined substance is discharged in its entirety, making the blending process thorough and efficient. Abster Machine’s commitment to high quality machines makes them a preferred choice among mini double cone blender manufacturers and laboratory mixer machine manufacturers. With a focus on delivering high-performance blending equipment, Abster continues to be a trusted name in the industry.
It is controlled by a PLC system, making it fully automatic for loading and discharging materials
The blender has a conical shape at both ends, which helps to uniform mixing and easy discharge of materials
It has a butterfly valve at one end for material discharge, and a hole with an openable cover at the other end for material charging and cleaning
The butterfly discharge valve is clamped to the blender outlet, allowing for quick disassembly and easy cleaning and maintenance. The valve flange seal can be customized to fit the customer’s product container
There is a 0-degree position for material discharge
The blender is equipped with special PLC programming and safety interlocks to operator safety
It uses a shaft-mounted gear motor installed via a shrink disc coupler, eliminating the need for traditional gear drive maintenance. The speed can be regulated using an AC variable frequency
The powder is filled up to two-thirds of the blender’s volume for proper mixing. As the blender rotates continuously, the material inside moves in a complex and vigorous manner, resulting in uniform mixing. The conical shape at both ends helps achieve even mixing and makes it easier to discharge the mixed product.
The blended product can be discharged from the bottom of the blender using a butterfly valve. This high-quality blender operates smoothly and efficiently, providing reliable and trouble-free performance throughout the mixing process.
Capacity Table Double Cone Blender
| Model | DCB 5 | DCB 10 | DCB 15 |
|---|---|---|---|
| Gross Capacity | 5 Liter | 8 Liter | 15 Liter |
| Working Capacity | 2 Liter | 4 Liter | 10 Liter |
| MOC (Material of Construction) | SS316/SS304 | SS316/SS304 | SS316/SS304 |
| Design Type | Cantilever Design | Cantilever Design | Cantilever Design |
| Design Feature | Interchangeable Bowl | Interchangeable Bowl | Interchangeable Bowl |
| Drive | 0.5HP, 1440RPM, 3Phase, NFLP | 0.5HP, 1440RPM, 3Phase, NFLP | 0.5HP, 1440RPM, 3Phase, NFLP |
| Power Voltage | 440V, 3Phase, 50Hz | 440V, 3Phase, 50Hz | 440V, 3Phase, 50Hz |
